تفاصيل المنتج:
|
| وزن: | 29 كجم | مادة: | الصلب المكربن |
|---|---|---|---|
| حجم المطرقة: | 3 بوصة | خيط: | 3 '' remet |
| قطر خارجي: | 81 ملم | طول: | 1069ملم |
| نطاق ثقب: | 84-105mm | ضغط الهواء: | ضغط هواء مرتفع |
| ضغط العمل: | 1.5-3.5Mpa | معدل التأثير: | 30 هرتز في 2.4mpa |
| سرعة الدوران: | 25-40r/دقيقة | استهلاك الهواء: | 7-14 متر مكعب/دقيقة |
| بت عرقوب: | SRC531 | موضوع الاتصال: | 3 '' remet |
| نوع الآلة: | أداة الحفر | ||
| إبراز: | 3 inch Down The Hole Hammer,1069mm Length Down The Hole Hammer,81mm External Diameter Down The Hole Hammer,1069mm Length Down The Hole Hammer,81mm External Diameter Down The Hole Hammer |
||
Reverse circulation drilling efficiently collects uncontaminated samples by transporting them through a hollow pipe system. This method prevents sample contamination from surface materials, ensuring accurate geological analysis.
| Length (less bit) | Weight (less bit) | External Diameter | Bit Shank | Hole Range | Connection Thread |
|---|---|---|---|---|---|
| 1069mm | 29.0kg | 81mm | SRC531 | 84-100 | 3''Remet |
| Working Pressure | Impact Rate at 2.4Mpa | Recommended Rotation Speed | Air Consumption | ||
|---|---|---|---|---|---|
| 1.5-3.5Mpa | 30HZ | 25-40r/min | 1.7Mpa: 7 m³/min | 2.4Mpa: 10 m³/min | 3.0Mpa: 14 m³/min |
Available shipping methods: By sea, by air, or by express
